Metal Fabrication / Skid plates - ***Drawings***

L300Foca · Post by **L300Foca** » Fri Feb 03, 2012 4:22 am

AWSOME POST

TNX

pajerry · Post by **pajerry** » Mon Feb 06, 2012 9:21 am

Love the individual touch on those ones. What was the total damage all said and done?

The way I off-road is that if something is steep like a ditch, I will inch into it, if I hear a scraping sound I stop

Your inching down causes your van to want to endo :) I Wish I had captured some of the better examples from that day, there were a few good ones riding the brakes.

Post by **nxski** » Mon Feb 06, 2012 9:51 am

Very true, the inching was to save the radiator guards of which I did sheer off one (it's back in place now though). There was absoloutely no damage to the skid plate thankfully.
I suppose whipsaw was more like inch-inch-inch-clench and let go of the brakes.

pajerry · Post by **pajerry** » Tue Feb 07, 2012 12:41 pm

too true. Very entertaining

Tojo · Post by **Tojo** » Fri Feb 10, 2012 12:38 pm

Downloads for a PDF fully dimensioned drawing, PDF one to one scale drawing and DXF outline file for a waterjet cutter (in a ZIP folder).
All for an automatic transmission L300 Delica.

*EDIT: Bend diagram attached. Drawings have been revised June 11th, 2012

Thanks to NXSKI for releasing this for FREE to the world. LOL!
Happy Bashing!

almac · Post by **almac** » Fri Feb 10, 2012 4:17 pm

will the designs work on a laser cutter? and do you have designs for the 5sp manual transmission?

Post by **nxski** » Fri Feb 10, 2012 4:22 pm

almac wrote:
will the designs work on a laser cutter? and do you have designs for the 5sp manual transmission?

I can send you the rough AutoCAD plans for the 5 speed or of you're bribe Tojo he might be able to finish them off for you!?

The problem is that Tojo modified my drawings and added dimensions based on my trial and error. I have no existing skid plate that I have created for a 5 speed, just dimensions that SHOULD work.

shealy · Post by **shealy** » Fri Feb 10, 2012 10:55 pm

So if we take that .dxf file that Tojo just posted to a place that does metal fabrication and has a waterjet cutter, then they should be able to do it? (minus the bends of course....)

By the way: thanks for these plans!

almac · Post by **almac** » Sat Feb 11, 2012 12:02 am

i think my machine uses .ncf files. i'll look into some kind of conversion...

Post by **nxski** » Sat Feb 11, 2012 2:12 am

The Waterjet cutters I took mine to used AutoCAd drawings. It appears that there's no industry standard.

Tojo · Post by **Tojo** » Sat Feb 11, 2012 8:05 am

Hey Guys,

I can do up the manual transmission drawings on Monday when I'm back at the workstation doing 'work' ha ha. It appears that it's mostly the same except for the cutout. However, the manual trans version hasn't been made and tested yet, NXSKI and I both have autos, so you'll be the guinea pig. Most of the waterjet cutters that I've worked with can use DXF or DWG files. I'll look and see if I can convert to .ncf, probably can.

As for waterjet vs. laser cutting: http://www.teskolaser.com/waterjet_cutting.html
Waterjet can cut thicker material. But a laser cutter can cut up to 0.4" material depending on the strength of the machine.

On a side note, it would be cool to cut a Mitsumaple logo into the top of the plate. Also, if there is interest, we should get a bunch of skidplates made at once to bring the cost down.

Cheers,
Tojo

shealy · Post by **shealy** » Sat Feb 11, 2012 12:31 pm

Well count me in as interested if we do some sort of group fabrication. I like the idea of a mitsu-maple or something on the plate - I'm sure more airflow holes to that rad, the better too. Keep me posted, cheers!

-Steve

almac · Post by **almac** » Sun Feb 12, 2012 6:58 pm

i work on a laser machine daily that is capable of cutting up to 1/2" steel.
while the mitsumaple sounds cool, i would rather just have a regular maple leaf.
please keep me posted.

Tojo · Post by **Tojo** » Thu Feb 16, 2012 4:22 pm

Manual transmission L300 production drawing, one to one PDF and DXF file (in a ZIP folder) attached.

NOTE: this has not been tested, so it's highly recommended to make a cardboard template for proof of concept!

L300Foca · Post by **L300Foca** » Fri Feb 17, 2012 11:40 am

Tojo wrote:Manual transmission L300 production drawing, one to one PDF and DXF file (in a ZIP folder) attached.

NOTE: this has not been tested, so it's highly recommended to make a cardboard template for proof of concept!

TNX Bro
